Match Textile offers a modular approach with the implementation of feature packages that suites customer’s specific needs. A point system rates the value of each individual feature. The program can be configured for 5,10,15,20,25 and 30 points. Only package of 5 points increment can be purchased.
Datacolor Match Textile in defined product level includes Datacolor Tools, a color quality control software License.
| Feature Package |
# of Points |
| Fast correction capabilities |
1 |
| Manual recipe input |
1 |
| storage and use of additional effects |
1 |
| Batch matching |
1 |
| Min/Max Dyestuffs limits |
1 |
| Advanced SmartMatch functionality |
5 |
| Multicolor match |
2 |
| Multi-illuminant match |
2 |
| Easy click restoring o recipe tables |
1 |
| Sensitivity values |
1 |
| Fixed relations of Dyestuffs pairs |
1 |
| Automatic build-up of Dyestuff groups |
3 |
| Lab process |
3 |
| Advanced data view designer |
2 |
| Center side QC |
5 |
Datacolor Match Textile is offered at different functionality levels to satisfy individual customer requirements. The basic level serves all general color matching needs and comes bundled with Datacolor Tools, a leading color QC software.
Advanced formulation functions
- Create recipes for exhaust, continuous and pad batch dyeing, printing and fiber blending
- Advanced recipe history, data sorting and search capabilities
- Multiple recipe optimization options including weight of dH and NEW color constancy
- NEW: Customer-dependent settings for match prediction can be stored
- NEW: User-defined recipe status and location
- NEW: Export features including theoretical curves and export to MS-EXCEL
- NEW: Offset matching for any standard
Superior recipe correction functions
- Correct one or all parts of a blended fabric
- Colorimetric analysis for corrective decisions
- NEW: Shade correction based on minimized dH
- NEW: Offset standards for process-dependent recipe correction
Dyeset Preparation Functions
- Chemicals stored during dyeset preparation
- Up to 16 levels for dyestuff characterization
- NEW: Ingredient compatibility manager
- NEW: Dyeset quality analysis
Optional functions AVAILABLE as feature packages
- Batch matching & fast correction
- Storage and use of additional effects (substrate, etc.)
- Advanced Smart Match® with automated housekeeping
- Multi-illuminant and multi-color match
- Create dyestuff groups based on dyestuff technical data
- Work with fixed dyestuff relationships and concentration limits
- Complete lab dyeing procedures
| Component |
Recommended Minimum (Stand Alone) |
| Processor |
Dual Core Processor @ 2 GHz or faster |
| Memory |
4 GB or more |
| Hard Disk Drive |
500 GB |
|
|
|
| Video Memory |
512 MB |
| CD/DVD Drive |
DVD Reader (DVD Writer recommended) |
| Diskette Drive |
|
| Available Ports |
RS-232, USB, Printer Port: Parallel or USB
|
| Printer Port |
USB or Parallel |
|
|
Windows® 7/8/10/11 Pro (32 or 64 bit) For Terminal Server: Windows® Server 2008 / Windows® Server 2012, Gigabit or faster networking |
